Olympus’ new Vanta™ analyzer is our most advanced handheld X-ray fluorescence (XRF) device. These rugged, powerful, and intuitive instruments provide rapid, accurate element analysis and alloy identifications to customers who demand laboratory-quality results in the field.
Vanta handheld XRF analyzers are some of the toughest devices Olympus has ever made. Their rugged and durable design makes them resistant to damage for greater uptime and a lower cost of ownership. With intuitive navigation and configurable software, the Vanta series are easy to use with minimal training for high throughput and fast return on investment. Olympus’ innovative Axon™ technology means Vanta analyzers give you accurate results and help boost productivity no matter the environment or working conditions.
• Exceptional durability under extreme conditions
• Analytical excellence
• Optional Wi-Fi and Bluetooth® for real-time data sharing
• Intuitive user interface
Rugged
Breakdowns cost time and money. Vanta analyzers are durable for increased uptime and a low cost of ownership. And with an included three-year warranty, you can be assured that we stand by the ruggedness of Vanta analyzers.
Built to thrive in the toughest working environments, Vanta analyzers are:
* M Series analyzers are IP64 rated.
** With optional fan. The fan assembly is IP56 rated. Operates continuously at 33 °C without the fan.
Vanta analyzers give you the same accurate result every time from your first test to your hundredth test.
The Vanta Series’ proprietary Axon™ technology uses ultra-low-noise electronicsenabling higher X-ray counts per second for fast, accurate, and repeatable results.
Axon technology coupled with a new quad-core processor make Vanta analyzers remarkably responsive, pushing the limits of performance so you get the best results in the least amount of time. Axon technology provides remarkable test-to-test and instrument-to-instrument repeatability, so your first test is the same as your last test no matter what instrument you may use.
Vanta analyzers maximize user throughput and make data archiving easy. Application-specific software features improve user productivity for fast ROI.
Dimensions (W x H x D) |
8.3 x 28.9 x 24.2 cm (3.25 x 11.4 x 9.5 in.) |
Weight |
1.70 kg (3.75 lbs) with battery, 1.48 kg (3.25 lbs) without battery |
Excitation Source |
4-Watt X-ray tube with application optimized anode material |
M Series (Rh & W) and C Series (Ag): 8-50 kV |
|
C Series (Rh & W): 8-40 kV |
|
Primary Beam Filtration |
8-position auto selected filter per beam per mode |
Detector |
M Series: Large area Silicon Drift Detector |
C Series: Silicon Drift Detector |
|
Power |
Removable 14.4 V Li-Ion battery or |
18 V power transformer 100-240 VAC, 50-60 Hz, 70 W max |
|
Display |
800 x 480 (WVGA) LCD with capacitive touch-screen |
Operating Environment |
Temperature: -10 °C to 50 °C (continuous duty cycle with optional fan) |
Humidity: 10% to 90% relative humidity non-condensing |
|
Drop Test |
Military Standard 810-G 4-foot (1.3 M) drop test |
IP Rating |
IP65*: dust tight and protected against water jets from all directions |
Pressure Correction |
Built-in barometer for automatic altitude and air density correction |
GPS |
Embedded GPS/GLONASS receiver |
Operating System |
Linux |
Data Storage |
4 GB embedded storage, micro SD slot for expandable storage |
USB |
(2) USB 2.0 type A host ports for accessories such as Wireless LAN Bluetooth®, and USB flash drives. |
(1) USB 2.0 type mini-B port for connection to computer |
|
Wireless LAN |
Supports 802.11 b/g/n (2.4 GHz) via optional USB adapter |
Bluetooth |
Supports Bluetooth® and Bluetooth Low-Energy via optional USB adapter |
Aiming Camera |
Full VGA CMOS camera |
Panorama Camera |
5-megapixel CMOS camera with autofocus lens |
