TZM0756 is designed with modularized structure which is based on the bilateral parallel light path.with excellent optical performance. The TZM0756 can be used in the fields of machine vision, industrial inspection and scientific research.
| Order Number | Meaning | TZM0756 | Postfix meaning |
|---|---|---|---|
| TZM0756TD | Middle Zoom Module with back focus trimmable and magnification detent functions |
ZM ：Zoom 0756 ：0.7X~5.6X |
TD ：Trim & Detent |
| Order number | Magnification | Working distance(mm) | Field of View in the object side(TV050，1/3″sensor) | |
|---|---|---|---|---|
| Lower | Higher | |||
| W100 | 1.00X | 80 | 17.14mm | 2.14mm |
