Thông số kỹ thuật đồng hồ so 543-585
|
Range:
|
5,08 mm
|
|
Digital step:
|
0,01/0,001 mm
|
|
Inch-Metric:
|
Metric
|
|
Max. Permissible Error (Total Range):
|
0,003 mm
|
|
H MPE (Hysteresis):
|
0,002 mm
|
|
Type:
|
EN ISO Standard
|
|
Mass:
|
130 g
|
|
Data output:
|
Yes
|
|
Measuring force:
|
≤2 N N
|
|
Scale:
|
Capacitance type, ABSOLUTE linear encoder
|
|
Max. response speed:
|
Unlimited
|
|
Alarm:
|
Low voltage, counting value composition error, overflow error, tolerance limit setting error
|
|
Power supply:
|
1 battery SR-44
|
|
Battery life:
|
approx. 7000 hours
|
|
Stem Ø:
|
8 mm
|
|
Display:
|
LCD, character height: 6.2 mm
|
|
Protection:
|
IP66
|
|
Max. response speed:
|
Unlimited
|
|
Delivered:
|
Including 1 battery
|
|
PRESET:
|
Yes
|
|
Low voltage alarm:
|
Yes
|
|
Counting direction switchable:
|
Yes
|
|
GO/±NG judgement:
|
Yes
|
|
Digimatic data output:
|
Yes
|
|
ON/OFF:
|
Yes
|
|
DATA (output with cable) / HOLD (display value):
|
Yes
|
|
External
PRESET / ZERO: |
Yes
|
|
Selectable resolution:
|
Yes
|
|
Contact point:
|
Carbide ball, thread M 2.5 x 0.45 mm
|
|
Digital/Analog:
|
Digital
|
This is a back-plunger model that is highly resilient and robust.
The ABSOLUTE Digimatic Indicator ID-B offers you the following features:
